DIY: Voltmeter

Discussion in 'DIY - Do It Yourself Forum' started by Sketch o5, Oct 10, 2005.

  1. Sketch o5

    Sketch o5 Señor Greengo

    Posts:
    22,488
    Likes Received:
    55
    Joined:
    Sep 6, 2005
    Location:
    .
    this was really easy, i just spliced the 2 wires for one of the gauge cluster lights, and fuse tapped for the 12volt hook up for the reading.

    [​IMG]
    the white wire and the black wire are for the light that lights up the volts gauge, thats why theyre just tapped into that cluster light, so that when i turn on my parking lights (at least) the gauge will light up like the rest of the dash.

    i spliced both grounds into the ground wire, cuz im lazy, and well, its just a ground.

    then i just ran the red power wire into the fuse pannel where i found a fuse that came on with the ignition, which i happened to pick my fuel pump.

    end product:
    [​IMG]

    Last edited: Jan 22, 2015
  2. okasu

    okasu Well-Known Member

    Age:
    31
    Posts:
    192
    Likes Received:
    0
    Joined:
    Sep 7, 2005
    oh so for the mean time your running handicap with one guage? lol get a patch you LAND PIRATE! HAHAHAHAH! So you thought I forgot about that one.

  3. Sketch o5

    Sketch o5 Señor Greengo

    Posts:
    22,488
    Likes Received:
    55
    Joined:
    Sep 6, 2005
    Location:
    .
    hahaha,nahh, i got both goin right now, its sweet. so HA! THIS LAND PIRATE SCORES AGAIN!!!!!!! aaarrggg, haha.

  4. okasu

    okasu Well-Known Member

    Age:
    31
    Posts:
    192
    Likes Received:
    0
    Joined:
    Sep 7, 2005
    LOL I heard that you land pirates are some sick bastards... just read for yourself.

    HAR!!!

  5. CrosCntryAccord

    CrosCntryAccord Well-Known Member

    Age:
    34
    Posts:
    8,297
    Likes Received:
    33
    Joined:
    Apr 20, 2007
    Location:
    Arlington TX
    ooo, the install of parts i wanna buy from andy! REVIVAL FTMFW

  6. FallenAngelHIM

    FallenAngelHIM Well-Known Member

    Age:
    32
    Posts:
    3,845
    Likes Received:
    8
    Joined:
    Nov 24, 2005
    Location:
    Miami, FL
    wow what a way to gain sails you ****tegnhagendouche lol

  7. dynasty

    dynasty Well-Known Member

    Age:
    32
    Posts:
    2,515
    Likes Received:
    6
    Joined:
    Jul 7, 2006
    i wired my volt meter to the cigerette lighter. i also added a wire from the firewall to it so i can get the most accurate voltages to be metered.

    [​IMG]

    my engine was off btw, so the volt is saying 11.5. when it's on, it goes to 12.5.

  8. Sketch o5

    Sketch o5 Señor Greengo

    Posts:
    22,488
    Likes Received:
    55
    Joined:
    Sep 6, 2005
    Location:
    .
    nice. i think mine read close to 14 or so when the car was fully on? i wired the one in my gti to the cigarette lighter too, and it reads just at 14.

  9. dynasty

    dynasty Well-Known Member

    Age:
    32
    Posts:
    2,515
    Likes Received:
    6
    Joined:
    Jul 7, 2006
    yeah. sometimes mine would jump to 14volts. but it's mostly constant in 13.5v for me.

  10. Totalimmortal

    Totalimmortal Well-Known Member

    Age:
    32
    Posts:
    2,897
    Likes Received:
    14
    Joined:
    Mar 4, 2006
    Location:
    Westminster, CO
    A healthy charging system should show around 12.6 at rest, without the car on. It should show 13.5 or more with the car on.
