Seat power and heat wiring diagrams

Discussion in 'Accord Tech' started by kn0x47, Aug 18, 2014.

  1. kn0x47

    kn0x47 Senior Member

    Posts:
    3,732
    Likes Received:
    18
    Joined:
    Mar 14, 2008
    Location:
    Birmingham, AL
    For anyone swapping in Acura CL seats, these diagrams should be useful. Pulled from a 98 accord manual. Sorry, I don't have CL information yet

    **I dunno why all the photos are sideways. I'll fix it later

    [​IMG]DSC_2553 by Jonathan Boothe, on Flickr

    [​IMG]DSC_2554 by Jonathan Boothe, on Flickr

    [​IMG]DSC_2555 by Jonathan Boothe, on Flickr

    [​IMG]DSC_2556 by Jonathan Boothe, on Flickr

    [​IMG]DSC_2557 by Jonathan Boothe, on Flickr

    [​IMG]DSC_2558 by Jonathan Boothe, on Flickr

    [​IMG]DSC_2559 by Jonathan Boothe, on Flickr

    If you have CL info feel free to post

    Last edited: Aug 18, 2014
    RedRyder likes this.
  2. RedRyder

    RedRyder Be a better driver

    Posts:
    19,180
    Likes Received:
    62
    Joined:
    Sep 5, 2008
    Location:
    Fawking, OH
    Stickied. Another 6GA Canada diagram, may be redundant:


    [​IMG]


    CL info, maybe someone has better quality versions of the bottom 3...


    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]


    Repped. Btw I think those are for CL-S, someone said the wiring was different between CL base and Type-S. Not sure if that’s true.

    Last edited: Aug 18, 2014
  3. briansan

    briansan Well-Known Member

    Posts:
    80
    Likes Received:
    0
    Joined:
    Nov 16, 2014
    Location:
    Havertown, PA
    so i parted out my car and my car seats are kind of just chilling in my living room.

    i thought it'd be cool to rewire the seats to work off an external power source. i don't see the specifications describing the wiring down to the resistances, etc. any suggestions??

  4. xci.ed6

    xci.ed6 Well-Known Member

    Posts:
    2,909
    Likes Received:
    8
    Joined:
    Sep 5, 2007
    Location:
    Tampa Bay
    blu/red = power
    blu/wht = ground

    for driver seat, of accord, for RECLINE only, switch still works.

  5. Dnguyen211

    Dnguyen211 Well-Known Member

    Posts:
    255
    Likes Received:
    0
    Joined:
    Aug 20, 2015
    Location:
    Iowa
    Do the us models accord have it prewired and we just have to supply with switches like the 01 gs300 did or do we have to completely wire the seats with fuses and such?

  6. kn0x47

    kn0x47 Senior Member

    Posts:
    3,732
    Likes Received:
    18
    Joined:
    Mar 14, 2008
    Location:
    Birmingham, AL
    no it's not prewired. You'll have to add all the wiring
