ULEV and non-ulev O2 sensor?

BoyRicer

Well-Known Member
Joined
Jun 13, 2011
Posts
114
Reaction score
0
Location
Albany Area NY
Is there a difference between the two sensors? I have an 01 ulev and im getting the p1167 code which is for the primary O2 sensor. The prices are either $40 for a denso for non ulev and 120 for the ulev.
Thanks


Simkid5614

Well-Known Member
Joined
Oct 11, 2012
Posts
551
Reaction score
3
Location
Delaware
Have fun paying the 120 I did. I used the Denso one. OEM parts :)


DENSO Part # 2349025

116.79 On Rockauto.com


Jimsun

Well-Known Member
Joined
Jul 25, 2012
Posts
428
Reaction score
3
Location
Toronto
There's a difference. I acidentally bought a non ulev shut off solenoid for my canister and i'm getting the same code.

Im waiting for the ulev valve to come fix the issue.


BoyRicer

Well-Known Member
Joined
Jun 13, 2011
Posts
114
Reaction score
0
Location
Albany Area NY
thanks for all the responses stupid cali engine, and im in NY just got lucky to get the eco engine haha


Dukebb23

Duke Blue Devils
Joined
Dec 16, 2012
Posts
640
Reaction score
3
Location
Smashville,TN
Yeah I feel you there. I am in TN and got one that came from NY with the Ulev engine.
But hell mine only had 65k when I got it in july 2012


Mapper64

New Member
Joined
Aug 23, 2013
Posts
1
Reaction score
0
Location
Townsend, mA
Make sure you get the right sensor for the upper - and you don't need to go to the dealership or fork out for a Bosch. My daughter's 2000 Honda Accord with the 2.3 liter ULEV VTEC engine tripped P1167 code. Took a look at both O2 sensors, and the downstream/lower/one in the CatCon had a broken wire. Replaced that one, but vehicle still tripped the P1167. Went to parts store for the upstream/upper/one in the exhaust manifold, and got the Denso universal 234-4209, which is shown on the Denso Site and in the Parts store computer as the right one. ($55) Soldered the wires to the connector, put it in, cleared the code, but after 5 minutes of running the code tripped again. More research revealed the upstream/upper sensor is NOT an O2 sensor (this is a common misnomer for that unit, and is called that everywhere) - it is in fact a Air/Fuel Ratio sensor, that is specific to the ULEV VTEC engine. Denso Part #234-9025 (direct fit, no connector soldering needed, plug & go). ($192 - ouch) Notice, the Denso box on the 234-4209 says Oxygen Sensor on it, but on the 234-9025, it says Air/Fuel Sensor on the box.
Cleared the code, problem solved.

The difference is the ULEV VTEC, which is indicated right on top of the engine valve cover. When looking up these sensors, the parts store computer asks "Is this a California Emissions engine?" We answered "don't know", and got the right part. Nobody, not even the parts store guy, seems to knows for sure if ULEV is the same as California Emissions. It also asked if this is a SULEV engine, which ours is not, maybe that's California Emissions?
