WTF is this wiring nightmare!!1!1

[Mike's_Taffeta]

So I saw a wire hanging down from under the dash, so I decided to investigate. I think I opened a can of worms. Can someone point out what these connectors go to, why there's an inline fuse connected to the obd connector and the other crap that doesn't look right lol.



[accord786]

dammmm thts a messsss!!!!!


heyy dude did u ever go to the meet last week?



[Mike's_Taffeta]

Didn't get to the meet, I had to set up for a party I really wanted to go too.



[Drift]

Just do it slowly and go through one wire at a time. Its only a car alarm.


I had a customer hack apart an entire EVO IV harness and wondered why his car no longer started. Had to repair this:



[shavedaccord]

a car alarm gone wrong



[CG6]

yea thats def a alarm bro... and as for the dude that took all that out a evo... what an idiot



[Mike's_Taffeta]

Holy poop I hate wiring. If there's one thing I'm not, its not a wire chaser. I can do everything else in a car except wiring. Mainly because I choose not to. The car has been running fine and everything, but it doesn't look right having open wires under there.

Ill probably attack it this weekend.

Can anybody tell me specifically what the last pic wires are? I have those on the passenger side as well and they go into the door.

Oh and drift, I think I have seen something like that in that movie arachnaphobia lol. What a mess.



[Drift]

Can anybody tell me specifically what the last pic wires are? I have those on the passenger side as well and they go into the door.

Oh and drift, I think I have seen something like that in that movie arachnaphobia lol. What a mess.

Any time there is a twisted set of wires like that, you can bet that some hoopty stereo shop did the work. Just start tearing sh!t apart.



[shavedaccord]

Probably the wireless entry part of the alarm.



[Mike's_Taffeta]

I have a dx, manual everything. So no keyless entry.
