Infinity speaker depth.

Simkid5614 · Dec 26, 2012

I know about it hitting, Crutchfield says it wont fit.
http://www.crutchfield.com/p_108R6500CX/Infinity-Reference-X-REF-6500cfx.html?tp=106#overview-tab

2 1/16th. or 52 MM fron speaker mount to magnet
2 1/2 inch or 64 MM from woofer to magnet

I know about cutting out the speaker brackets I want to know if everything will clear.
I wanted those because I can either choose to cut a hole in the door for the tweet or i can still undermount it to the factory.

schmiddr2 · Dec 26, 2012

I have never heard really good things about the Infinity Ref comps, but they are popular for some reason...so I would read some reviews. They will fit in the door. Use 1/2" treated plywood to make the baffle/speaker ring.

I use the JBL MS-62C which is also very shallow and works with a 5/8" baffle. I put the tweeters in the sail panels but they can be mounted in the OEM dash location or near the door speaker.

Simkid5614 · Dec 26, 2012

I was considering going with Kickers, Alpines or Rockford Fosgate.

I'll do some more research. I didnt think I could use that big of a baffle ring.

schmiddr2 · Dec 26, 2012

1/2" speaker ring will work with the Infinity. 5/8" works for the JBL. For either one you might need to round out the speaker opening so the basket of the speaker does not hit on the rim of the speaker opening, it is very close. http://www.6thgenaccord.com/forums/showpost.php?p=935050&postcount=16
