For those still seeking guidance in harness wiring here is your key (as long as your harness is the same or similar lol). Brought from the original 01-03 Civic thread, which was way too long for it's own good. I rummaged through there today to bring some info to this, shorter thread.
This is how the fogs are mounted on both sides - notice the brackets screwed into the side and bottom to hold it all together:
For spacing issues along the bottom edge of the fog light, you need to have accurately drilled the fog light holes, which would provide tension on the bottom edge of the bumper pulling it up while the light is secured. If holes are haphazard, or light is loose, and if your bumper naturally has a gaping bottom opening, you will have a gap there. So basically your lights need to be tight and have 'tension' on them.
As I understand, the issue at hand is a gap underneath the foglight, correct? Or is the problem a gap between outer edge of fog light and bumper?
As for preventing a gap on outer edge of foglight and bumper, this may help:
I'm using the natural pressure from the light wanting to make the gap and protrude, to push against the screw after it is clipped to the side and fully screwed it, it makes a barrier. So push the light in, screw in the screw, let go of the light, and it puts pressure on itself & the screw in the way prevents the gap. pic is ****ty, but it may help. If you don't have clips to do this, buy them! All needed hardware can be purchased for $3 at your local Ace Hardware.
There is
no set way to do this, so just be creative if my methods don't work. Experiment and have fun!
Please let me know if any clarification is needed in any of this, and feel free to rep if this helps you solve your issue
.
well maybe theres a way to fix that problem. I dont have any suggestion right now but hopefully RussianRed does.
