eggyhustles
Well-Known Member
Re: Need to decide what sub to go with
I dunno..i never really got down with IB subs
Ryan knows all about them, though.
I dunno..i never really got down with IB subs
Ryan knows all about them, though.
*Pics update Need to decide what sub to go with
- Thread starter dustint209
- Start date
ryan s
they dont think it
Re: Need to decide what sub to go with
cory's got 4 12s with like 3000w now...
i probably lose a dB or two with the seat up, but riding around with the back seat folded was high school **** the armrest doesn't make any difference if its up or down.
the biggest thing if youre going to do it this way is watching out for the folding pass-thru...it sticks out a LOT on the trunk side (the little pull handle thinger).
nevermind the wires and hardware...first pic i only had 4 screws holding the baffle and no hardware holding the sub theres a few more things holding it besides the brackets you can see...
oem carpet is back in...trunk "floor" is getting redone in 1/2" birch ply as we speak...
you must seal up all the big holes/holes you can see through etc...very important...
thats about right for sealed...i haven't messed with modeling them for a while now.
cory's got 4 12s with like 3000w now...
you can mount 1 15" right up against the seat. it wont quite fit into the opening. if you want 2, you'd have to either mount them further back or put the cones towards the trunk (doesn't matter much). one is enough for me, but i'll probably add another down the road just to get more of that lowest octave.
i probably lose a dB or two with the seat up, but riding around with the back seat folded was high school ****
the armrest doesn't make any difference if its up or down. the biggest thing if youre going to do it this way is watching out for the folding pass-thru...it sticks out a LOT on the trunk side (the little pull handle thinger).
nevermind the wires and hardware...first pic i only had 4 screws holding the baffle and no hardware holding the sub
theres a few more things holding it besides the brackets you can see...
oem carpet is back in...trunk "floor" is getting redone in 1/2" birch ply as we speak...
you must seal up all the big holes/holes you can see through etc...very important...
eggyhustles
Well-Known Member
Re: Need to decide what sub to go with
How is the output with IB setups?
When the trunk is closed, does it act like a big sealed box?
How is the output with IB setups?
When the trunk is closed, does it act like a big sealed box?
ryan s
they dont think it
Re: Need to decide what sub to go with
with a single 15" the output drops off below 30Hz or so (my Fc is like 29Hz or something close)...but i say that with the caveat that i never listen to anything but rock so 60-120Hz is more important to me.
also, the dropoff in output is similar to a 20Hz/12dB subsonic. it barely moves the response graph when i add one in, then remove it...so think of it like a subsonic-filtered system...people probably don't mind that too much, right?
IF i had another, Fc would go up to 36Hz, but it would be like 4.5dB louder at 20Hz. keeping in mind that it's 20Hz...2 IB15s would be at 108dB. at 50Hz (about where the sedan's transfer function is) figure 117dB plus 15-20 for cabin gain.
oh, and you need 150w per sub to reach Xmax. anything more is just unneeded...
with the trunk closed, it's exactly like a big (leaky) sealed box. that's ok, because we need the leaks to keep the Qts flat with 2 drivers.
with a single 15" the output drops off below 30Hz or so (my Fc is like 29Hz or something close)...but i say that with the caveat that i never listen to anything but rock so 60-120Hz is more important to me.
also, the dropoff in output is similar to a 20Hz/12dB subsonic. it barely moves the response graph when i add one in, then remove it...so think of it like a subsonic-filtered system...people probably don't mind that too much, right?
IF i had another, Fc would go up to 36Hz, but it would be like 4.5dB louder at 20Hz. keeping in mind that it's 20Hz...2 IB15s would be at 108dB. at 50Hz (about where the sedan's transfer function is) figure 117dB plus 15-20 for cabin gain.
oh, and you need 150w per sub to reach Xmax. anything more is just unneeded...
with the trunk closed, it's exactly like a big (leaky) sealed box. that's ok, because we need the leaks to keep the Qts flat with 2 drivers.
Last edited:
dustint209
Well-Known Member
Re: Need to decide what sub to go with
I did some reading on the IB setup and i'm really starting to like it. It would be real nice to have my trunk space and still have jam. Im thinking i could put the baffle in the trunk right behind the rear speaker holes and seal the baffle to the trunk. I would leave the rear speakers out to allow more bass in the cab. It would act like a port kinda. The FI IB315 is $189. https://ssl.perfora.net/www.ficarau...Speakers/0050_IB3/product_overview.shopscript
Is there any other good IB sub around that price?
I did some reading on the IB setup and i'm really starting to like it. It would be real nice to have my trunk space and still have jam. Im thinking i could put the baffle in the trunk right behind the rear speaker holes and seal the baffle to the trunk. I would leave the rear speakers out to allow more bass in the cab. It would act like a port kinda. The FI IB315 is $189. https://ssl.perfora.net/www.ficarau...Speakers/0050_IB3/product_overview.shopscript
Is there any other good IB sub around that price?
ryan s
they dont think it
Re: Need to decide what sub to go with
sure, you could put the baffle back further. only thing is you'll have to find a way to secure the bottom of the baffle (it will end up right over the void between the tire well and the tire)...the sides may be a little difficult as well. if youre not opposed to drilling into the tire well, that's not really a problem then.
i have an acoustic elegance IB15-A (which is a 4-ohm made specifically for the car). i can't remember if they're $129 or $149 each...but they're made to order so you have to call and order and then wait. wisconsin company too
if you order 4 at a time, they go for like $110 each...and since i kind of want another and the machined basket doesn't match my old style basket, i'd have to get a new pair for myself and sell the old one...they're willing to split orders if you catch my drift
specs here:
http://www.aespeakers.com/phpbb2/viewtopic.php?f=3&t=1647
sure, you could put the baffle back further. only thing is you'll have to find a way to secure the bottom of the baffle (it will end up right over the void between the tire well and the tire)...the sides may be a little difficult as well. if youre not opposed to drilling into the tire well, that's not really a problem then.
i have an acoustic elegance IB15-A (which is a 4-ohm made specifically for the car). i can't remember if they're $129 or $149 each...but they're made to order so you have to call and order and then wait. wisconsin company too
if you order 4 at a time, they go for like $110 each...and since i kind of want another and the machined basket doesn't match my old style basket, i'd have to get a new pair for myself and sell the old one...they're willing to split orders if you catch my drift specs here:
http://www.aespeakers.com/phpbb2/viewtopic.php?f=3&t=1647
dustint209
Well-Known Member
Re: Need to decide what sub to go with
I have a good bit of experience with cutting, drilling, finishing wood so i don't think that would be a problem. I would make a cardboard template first than cut the wood. I appreciate the offer on the speakers but i'll pass.
sure, you could put the baffle back further. only thing is you'll have to find a way to secure the bottom of the baffle (it will end up right over the void between the tire well and the tire)...the sides may be a little difficult as well. if youre not opposed to drilling into the tire well, that's not really a problem then.
i have an acoustic elegance IB15-A (which is a 4-ohm made specifically for the car). i can't remember if they're $129 or $149 each...but they're made to order so you have to call and order and then wait. wisconsin company too
specs here:
http://www.aespeakers.com/phpbb2/viewtopic.php?f=3&t=1647
I have a good bit of experience with cutting, drilling, finishing wood so i don't think that would be a problem. I would make a cardboard template first than cut the wood. I appreciate the offer on the speakers but i'll pass.
eggyhustles
Well-Known Member
Re: Need to decide what sub to go with
I've never heard ae but i've heard GREAT things about them.
Try them out OP
I've never heard ae but i've heard GREAT things about them.
Try them out OP
mkdb89-02se
Well-Known Member
Re: Need to decide what sub to go with
yea im not really big on highs... i just like bass.... but with a nice even high i mean... im satisfiyed with tha set up.... works and sounds great...
yea im not really big on highs... i just like bass.... but with a nice even high i mean... im satisfiyed with tha set up.... works and sounds great...
dustint209
Well-Known Member
Re: Need to decide what sub to go with
I was looking at the specs on my rockford fosgate and noticed that the qts is .62 and from what i've read it needs to be over .50 Only problem I see is the low xmax. Today is my day off of work so i'm thinking i could go spend about $10 on some mdf and build a baffle just to see how it would sound. If it sounds like poo i'll take it out and keep it for my next sub. What do you think? Go far it?
Description Value
CEA-2031 Compliant
Size 15"
Impedance 4-Ohm
Power Handling 200 Watts RMS
400 Watts Max
Voice Coil Diameter 1.5" 6-Layer
(3.81 cm)
Magnet Weight 54 oz.
Speaker Connector Dual 10 AWG compression
Fs (Hz) 24
Re (Ohms) 3.60
Le (mH) 3.9
Qms 7.50
Qes 0.67
Qts 0.62
Vas (Liters) 170.0
Sd (cm2) 860
SPL (dB @ 1w/1m) 87 dB
Xmax (mm) 9.5
Woofer Displacement 0.060 cu. ft.
(1.7 Liters)
Cutout Diameter 13.875 in.
(35.24 cm)
Mounting Depth 6.875 in.
(16.83 cm)
Shipping Weight 15.40 Lbs.
(6.98 Kg.)
I was looking at the specs on my rockford fosgate and noticed that the qts is .62 and from what i've read it needs to be over .50 Only problem I see is the low xmax. Today is my day off of work so i'm thinking i could go spend about $10 on some mdf and build a baffle just to see how it would sound. If it sounds like poo i'll take it out and keep it for my next sub. What do you think? Go far it?
Description Value
CEA-2031 Compliant
Size 15"
Impedance 4-Ohm
Power Handling 200 Watts RMS
400 Watts Max
Voice Coil Diameter 1.5" 6-Layer
(3.81 cm)
Magnet Weight 54 oz.
Speaker Connector Dual 10 AWG compression
Fs (Hz) 24
Re (Ohms) 3.60
Le (mH) 3.9
Qms 7.50
Qes 0.67
Qts 0.62
Vas (Liters) 170.0
Sd (cm2) 860
SPL (dB @ 1w/1m) 87 dB
Xmax (mm) 9.5
Woofer Displacement 0.060 cu. ft.
(1.7 Liters)
Cutout Diameter 13.875 in.
(35.24 cm)
Mounting Depth 6.875 in.
(16.83 cm)
Shipping Weight 15.40 Lbs.
(6.98 Kg.)
