5 Spd. F22 Swap installed... (some pics added )

[natzimus]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

badgertype or any1 familair with the swap.. answer me this..

this is the half shaft i bought.. its for a (93 prelude S) which is the same tranny i got.

and this is the Accord ( Manual) drivers side axle i am planning to buy
but they i cant see how they are gonno spline from these pics..
unless i bought the wrong halfshaft.

NOw this is an Automatic Halfshaft from the prelude.
this more looks like it will spline ..



[BlkCurrantKord]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

Could just be a generic axle picture.



[CHID0]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

badgertype or any1 familair with the swap.. answer me this..

this is the half shaft i bought.. its for a (93 prelude S) which is the same tranny i got.

That pic you posted still has the spline from the axle stuck in it....other than that it looks right.



[natzimus]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

That pic you posted still has the spline from the axle stuck in it....other than that it looks right.

oh okie..
need tranny swap soon.
tranny feeling weaker..
very driveable though



[natzimus]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

i am still looking for a line that connects the clutch master to the slave cylinder...
its either i am gonno have to make my own.. or modify a F23 manual one.



[natzimus]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

you can use the prelude one but i reccomend using a true cg line

what do u refer to as a Cg line ?



[BlkCurrantKord]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

Dude - http://www.tasauto.com/Product/Browse.aspx?d=792&sz=10&h=111&p=1

OR

www.hondaautomotiveparts.com

CG refers to our Chassis Code..



[natzimus]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

Dude - http://www.tasauto.com/Product/Browse.aspx?d=792&sz=10&h=111&p=1

OR

www.hondaautomotiveparts.com

CG refers to our Chassis Code..

bro.. its like.. i know where to get the stuff at
i get dealer prices etc.

but the problem is.. i dont have a F23 tranny. i have a F22
and i have a F22 slave cylinder, which is different than that of the F23 tranny.
the F23 tranny slave has a bracket that offsets it so the line could work..
also the F23 clutch line consists of a hard line and a soft line as 1..

pretty much.. i have to fab something up.



[BlkCurrantKord]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

Have you tried using the F23 bracket on the F22 cylinder...



[natzimus]

Re: Piecing the 5spd F22 Swap together.... ( tear down pics added )

wel.. i got the clutch, and pressure plate.

i bought a F22 halfshaft..

but i was told to get a driver side axle shaft..
but the one i bought i realized has 2 male ends, instead of having a female one..
i pretty much been buying the wrong parts here and there.. it sucks..

this is the one i purchased....
